NKI Needle Roller Bearings

NKI Needle Roller Bearings

Drawing

Datasheet

Bearing No.	Dimensions			Mass	Bearing No.	Dimensions			Mass
Bearing No.	d	D	B		Bearing No.	d	D	B
–	mm	mm	mm	kg	–	mm	mm	mm	kg
NKI 5/12	5	15	12	0.012	NKI 38/20	38	53	20	0.13
NKI 5/16	5	15	16	0.015	NKI 38/30	38	53	30	0.21
NKI 6/12	6	16	12	0.014	NKI 40/20	40	55	20	0.14
NKI 6/16	6	16	16	0.017	NKI 40/30	40	55	30	0.22
NKI 7/12	7	17	12	0.014	NKI 42/20	42	57	20	0.14
NKI 7/16	7	17	16	0.018	NKI 42/30	42	57	30	0.22
NKI 9/12	9	19	12	0.017	NKI 45/25	45	62	25	0.22
NKI 9/16	9	19	16	0.022	NKI 45/35	45	62	35	0.31
NKI 10/16	10	22	16	0.029	NKI 50/25	50	68	25	0.26
NKI 10/20	10	22	20	0.037	NKI 50/35	50	68	35	0.36
NKI 12/16	12	24	16	0.033	NKI 55/25	55	72	25	0.26
NKI 12/20	12	24	20	0.042	NKI 55/35	55	72	35	0.36
NKI 15/16	15	27	16	0.039	NKI 60/25	60	82	25	0.39
NKI 15/20	15	27	20	0.049	NKI 60/35	60	82	35	0.55
NKI 17/16	17	29	16	0.042	NKI 65/25	65	90	25	0.46
NKI 17/20	17	29	20	0.053	NKI 65/35	65	90	35	0.66
NKI 20/16	20	32	16	0.048	NKI 70/25	70	95	25	0.51
NKI 20/20	20	32	20	0.06	NKI 70/35	70	95	35	0.72
NKI 22/16	22	34	16	0.052	NKI 75/25	75	105	25	0.64
NKI 22/20	22	34	20	0.065	NKI 75/35	75	105	35	0.91
NKI 25/20	25	38	20	0.08	NKI 80/25	80	110	25	0.68
NKI 25/30	25	38	30	0.12	NKI 80/35	80	110	35	0.96
NKI 28/20	28	42	20	0.092	NKI 85/26	85	115	26	0.74
NKI 28/30	28	42	30	0.14	NKI 85/36	85	115	36	1.05
NKI 30/20	30	45	20	0.11	NKI 90/26	90	120	26	0.78
NKI 30/30	30	45	30	0.17	NKI 90/36	90	120	36	1.1
NKI 32/20	32	47	20	0.11	NKI 95/26	95	125	26	0.82
NKI 32/30	32	47	30	0.17	NKI 95/36	95	125	36	1.15
NKI 35/20	35	50	20	0.12	NKI 100/30	100	130	30	0.99
NKI 35/30	35	50	30	0.19	NKI 100/40	100	130	40	1.35
